Full Color Indoor Led Display Screens Signs P3 Advertising Panel 1500cd/m2 Brightness

Full Color Indoor Led Display Screens Signs P3 Advertising Panel 1500cd/m2 Brightness
Full Color Indoor Led Display Screens Signs P3 Advertising Panel 1500cd/m2 Brightness

Large Image :  Full Color Indoor Led Display Screens Signs P3 Advertising Panel 1500cd/m2 Brightness

Product Details:
Place of Origin: China
Brand Name: MLED
Certification: CE/RoHS
Model Number: P3
Payment & Shipping Terms:
Minimum Order Quantity: 1 square meter
Price: USD 530-600Per Square Meter
Packaging Details: Carton box/ Poly wooden case/ Flight case
Delivery Time: 1-7 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000 Square Meter Per Month
Detailed Product Description
Product Name: China Factory Supplied Top Quality Indoor Full Color P3 Led Advertising Panel / Led Screen Display Brightness: 1500cd/m2
Led Lamp: Hongsheng Kinglight Nationstar Usage: Indoor Advertising
Rafresh Rate: 1920HZ Power Supply: G-energy
Warranty: 2 Years Color: Full Color
High Light:

led display screen

,

full color led display

China factory supplied top quality indoor full color P3 led advertising panel / led screen display

Product advantages

1. Strong luminous intensity: within the visible distance, when the sunlight is directly on the screen surface, the display content is still clear and visible.



2. Good visual angle: it has large visual angle in horizontal and vertical, which is suitable for the environment with wide horizontal distribution and large height drop.



3. The effect is good: using non-linear point by point correction technology, the text is clearer and the sense of hierarchy is stronger;



4. Strong reliability: it adopts distributed scanning technology and modular design technology, with higher reliability and stability;


Product description

Item
Parameter
Unit Module
Model Number
P3-32S
Module size
192mm*192mm
Pixel pitch
3mm
Pixels Density
111111pixel/m2
Pixel configuration
1R1G1B
Package mode
SMD2121
Pixel resolution
64dots(W)*64 dots(H)
Port type
hub75/HUB3.0
Max Power
25W
Module thickness
12-14mm
Weight
0.18kg
Drive type
Constant drive
Scan mode
1/32scan
Brightness of white balance
≥1200cd/m2
LED
Cabinet
Dimension
576mm*576mm
Monomer Module Number
18
Power supply
5V/80A*1 pcs
Thermal discharge
anto
Pixel per cabinet
192mm*192mm
Best viewing distance
6M~40M
Best viewing angle
160°(W) 120°(H)
Temperature
storage:-35℃~+85℃
working:-20℃~+50℃
Relative humidity
10%-95%
Thickness
80mm
power
Working voltage
AC220V±10%
Average Power consumption
270W/㎡
Max.Power consumption
≤680W/PC
Current
≤20mA(single LED)
Control system
CPU
Pentium4 or above P4
Operation system
WIN98/2000/NT/XP/WIN7
Control method
Synchronization
Main technical
parameter
Driving device
Constant drive IC
Refresh frequency
≥1200HZ
Grey scale/colors
4096gray level/16.7M colors
MTBF
≥9000hours
Fire rate
Grade one
Display Mode
≥800*600/1024*768
Module size:192*192mm
Full Color Indoor Led Display Screens Signs P3 Advertising Panel 1500cd/m2 Brightness 0
Module size:192*96mm
Full Color Indoor Led Display Screens Signs P3 Advertising Panel 1500cd/m2 Brightness 1

 Product application

Full Color Indoor Led Display Screens Signs P3 Advertising Panel 1500cd/m2 Brightness 2

 About us

Full Color Indoor Led Display Screens Signs P3 Advertising Panel 1500cd/m2 Brightness 3

Full Color Indoor Led Display Screens Signs P3 Advertising Panel 1500cd/m2 Brightness 4

Training Free of charges;In our workshop, we provide all the training including process of operation, installation, maintenance, system set up, etc.
Warranty 1, 2years, .From beginning of installation finished the led display, During it , we will be responsible for all the quality problem.

2, After the completion of the project, we will conduct life maintenance of the system continuously and update the and software.

3, For the hardware equipment, we only collect expenses on components.



Guarantee 1, All the life time for Technology support , system update ,maintenance .



2, We guarantee that the equipment we provide are brand new, complete and unused before delivery .





Remark 1. We are manufacturer of LED display. We only provide the Screen, Cabinet and module, but do not take charge for the installation in overseas; Technical support is available.



2. The above offer included the cabinet, power supply, power cord,and other basic components; etc.



3. The above offer do NOT included the delivery, insurance, installation and debugging cost;



4. Packing with Ply-wood box, or Carton ; If need flight case packing, up cost will be USD180/PC, 2-4cabinets/case



5.Problems during use. some spare parts for you, once the screen get problems, please follow up below steps to solve it:



Step1: Take some pictures about the working status of the screen;



Step2: Replace the broken cabinet by the new cabinet;



Step3: Contact with us, and send the pictures to us, we will help you to analyze the problems.



Step4: If it is necessary, please post it to our company, we will maintain it for you as soon as possible, and then deliver it to you.
