P5 Mm Outdoor Taxi Led Display SMD 2727 Super Brightness 6500cd Brightness

China P5 Mm Outdoor Taxi Led Display SMD 2727 Super Brightness 6500cd Brightness supplier
P5 Mm Outdoor Taxi Led Display SMD 2727 Super Brightness 6500cd Brightness supplier P5 Mm Outdoor Taxi Led Display SMD 2727 Super Brightness 6500cd Brightness supplier P5 Mm Outdoor Taxi Led Display SMD 2727 Super Brightness 6500cd Brightness supplier P5 Mm Outdoor Taxi Led Display SMD 2727 Super Brightness 6500cd Brightness supplier P5 Mm Outdoor Taxi Led Display SMD 2727 Super Brightness 6500cd Brightness supplier P5 Mm Outdoor Taxi Led Display SMD 2727 Super Brightness 6500cd Brightness supplier P5 Mm Outdoor Taxi Led Display SMD 2727 Super Brightness 6500cd Brightness supplier

Large Image :  P5 Mm Outdoor Taxi Led Display SMD 2727 Super Brightness 6500cd Brightness

Product Details:

Place of Origin: China
Brand Name: Mled
Certification: CE RoHS FCC
Model Number: T-P5-15B

Payment & Shipping Terms:

Minimum Order Quantity: 1PC
Price: 1USD-100000USD
Packaging Details: Carton box,wooden case,flight case
Delivery Time: 5-10 days
Payment Terms: T/T, Western Union, MoneyGram, Western Union, MoneyGram
Supply Ability: 50000PS
Contact Now
Detailed Product Description
Name: P5mm Outdoor SMD2727 Super Brightness 6500nits For Taxi Roof Led Display Color: Full Color
Pixel Pitch: 5mm Application: Taxi,car
Warranty: 2years Lifespan: 100000hrs
Brightness: 6500cd Weight: 35kg
Package: Plywood

P5mm outdoor SMD2727 super brightness 6500nits for taxi roof led display

Specifications

Display Specification
1 Pixel pitch 5 mm
2 Resolution 40,000 dots/sq.m
3 Display size (each side) W 0.96 × H 0.32 = 0.3072 sq.m
4 Screen resolution (each side) W 192 × H 64 = 12,288
5 Total module quantity (each side) W 6 × H 2 = 12 pcs
6 Total cabinet quantity 1 pc
7 Cabinet size (including frame) W 1060 × H 400× D 135 mm
8 Power consumption (Max.) 800 W
9 Power consumption (Ave.) 435 W
10 Maximum Current 54.5 Amp
LED Module Specification
11 LED composition 1R 1G 1B
12 LED type SMD2727
13 Module resolution W 32 × H 32
14 Module size W 160 × H 160 mm
15 Driving method 1/8 scan constant current
Cabinet Specification
16 Cabinet material Aluminum cabinet with frame
17 Cabinet color Black
18 Cabinet weight about 25kg
19 Flatness Less than 1mm juncture
Optical Parameters
20 Brightness 6500 nits/sqm
21 Viewing angle Horizontal 140°, vertical 140°
22 Minimum viewing distance 5 m
Power Supply
23 Power supply DC 9 ~ 36V
24 Output voltage DC 5V
Control System
25 Control card Sheenled
26 Memory 4G
27 Control method 3G
28 Refresh rate 480 HZ
29 Refresh frame frequency 60~85 HZ
Formats Supported
30 Video AVI, WMV, MPG, MOV, DAT, VOB, MP4, FLV
31 Animation GIF, SWF
32 Picture JPG, BMP, WMF
Reliablity
33 Protection grades IP65
34 Work temperature -20~+60ºC
35 Humidity(RH) 10~90%
36 LED Life span More than 100,000 hours
37 MTBF 5000 hours
38 Out of controll dot rate Less than 1/10,000
Project Quotation
Item Quantity Unit Unit Price(USD) Total Price(USD)
P5 Taxi Top LED Display 1 set
LED Module 1 pc   Free Charge
Plywood Case 1 pc   Free Charge
LED Software 1 pc   Free Charge
LED Lamp standard pc   Free Charge
Driving IC standard pc   Free Charge
5V Power Supply Cable standard pc   Free Charge
Flat Cable to Connect Module standard pc   Free Charge
Screw at the Back of LED Module standard pc   Free Charge
Screw in Front of LED Module standard pc   Free Charge
TOTAL PRICE (EXW)
Package
Packaging size(per pc) L 110 × W 26 × H 50 cm
Package material Plywood
Quantity 1 pc
Inner pack EPE foam
Total CBM 0.2
N.W about 25 kg
G.W about 35 kg






Products Advantages:

1) Price Advantage: we have the best competitive price at the market; also have the same even better quality;
2) Performance Advantage: Best Equality, high consistency, Big viewing angle, can repair each led lamps;
3) Quality advantage: From material to finished product, from design to produce, we control all steps that are the guarantee of the quality and reliability;
4) Service advantage: Better service at same situation, better cooperation at same service.



 P5 Mm Outdoor Taxi Led Display SMD 2727 Super Brightness 6500cd Brightness


Packaging & Shipping


Plywooden case or flight case



Our Services


1) Your inquiry related to our products or price will be replied in 24hrs

2) OEM&ODM,any your customized lightings we can help you to design and put into product

3) Distributoership are offered for your unique design and some our current models

4) Protection of your sales area,ideas of design and all your private information

5) Top Quality+Reasonable Price+Responsible After Service=Successful & Win
