Product Details:
Payment & Shipping Terms:
|
| Product Name: | 3G/wireless P5 Taxi Top Advertising LED Screen Display | Application: | Car |
|---|---|---|---|
| Display Primary Color: | Rgb | Pixel Pitch: | 5mm |
| Driving Method: | 1/8 Scanning | Power Consumption: | 400w/m2 |
| Input: | 12v | Material: | Al |
| Highlight: | taxi top led display,LED Taxi Sign |
||
3G / wireless P5 Taxi LED Display screen Low power consumption
Specifications
| Numbers | Technical indexes | P5 Taxi Top LED Display |
| 1 | Pixel pitch | 5mm |
| 2 | Module size | 160mm× 160mm |
| 3 | Module resolution | 32× 32 |
| 4 | Module density | 40, 000dots/sqm |
| 5 | Pixel configuration | RGB ( SMD 3 in 1 ) |
| 6 | Red wavelength | 625± 2nm |
| 7 | Green wavelength | 525± 2nm |
| 8 | Blue wavelength | 470± 2nm |
| 9 | Colors | 16777216 |
| 10 | Best viewing distance | more than 5 m |
| 11 | Horizontal viewing angle | 140° |
| 12 | Vertical viewing angle | 140° |
| 13 | Maximum power consumption | ≤ 1200W/m2 |
| 14 | Brightness | ≥ 3000cd/m2 |
| 15 | Gray scale | 16bits of per color |
| 16 | Color temperature | 6500K |
| 17 | Control method | Asynchronization with 3G |
| 18 | Driving method | 1/8 scanning |
| 19 | Frame frequency | 60Hz |
| 20 | Refresh frequency | ≥ 2000 Hz |
| 21 | Working voltage | AC220V/110V± 10% |
| 22 | IP grade | IP65 |
| 23 | Working temperature | -20° C~80° C |
| 24 | MTBF | More than 10, 000 hours |
| 25 | Life span | More than 100, 000hours |
The functions of control system:
1. Off-computer after typed in the contents, one main board and several receiving boards.
2. The effect is as good as the main stream synchronous card, own the perfect playing effect
3. It has complete display function dominated by videos , and supports images and words.
4. It’s especially suitable for bar display, and the ultra-long or high length-width ratio is different from that of computer and TV display.
5. It’s designed based on products. We don’t undertake the project and add special functions without permission, and give priority to the stability.
6. We don’t’ work on the control of large LED, but focus on the low-cost and easily maintainable LED display.
7. It isn’t the video-type asynchronization and has long memory of programs. It can collect the temperature and automatically adjust the brightness.
Competitive Advantage:
1, Good quality;
2, Good price;
3, Good 24hours service;
4, Promote delivery;
5, Energy-saving;
6, Small order accepted.
