Advertising 45W 6500cd/m2 P5 Truck Led Billboard

Advertising 45W 6500cd/m2 P5 Truck Led Billboard
Advertising 45W 6500cd/m2 P5 Truck Led Billboard

Large Image :  Advertising 45W 6500cd/m2 P5 Truck Led Billboard

Product Details:
Place of Origin: China
Brand Name: MLED
Certification: CE/RoHS
Model Number: P5
Payment & Shipping Terms:
Minimum Order Quantity: 1 square meter
Price: USD 390-450 Per Square Meter
Packaging Details: Carton box/ Poly wooden case/ Flight case
Delivery Time: 1-7 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000 Square Meter Per Month
Detailed Product Description
Product Name: P5 Innovative Products 2020 Outdoor Advertising Truck Mobile Led Billboard /Video Screen Pixel Pitch: 5mm
Module Size: 320mm*160mm Brightness: 6500cd/m2
Waterproof: IP65 Level Led Chip: Epistar + Opto + Silan
Driving Method: 1/8 Scaning
High Light:

45W Truck Led Billboard


6500cd/m2 Truck Led Billboard


P5 Mobile Led Video screen

P5 Innovative Products 2020 Outdoor Advertising Truck Mobile Led Billboard /Video screen

Product advantages


1.The quality module

All modules and chips are purchased from leading suppliers from across the world. We take great care of quality and performance, and thus we remain very careful while selecting the modules and chips. LED chip is provided by Epistar, Cree, Nichia and Opto. Quality IC supplied by MBI, TMS, PWM and Mingyang.


2.Super visual impact

The height of truck led display just same as the pedestrian line of sight, advertising information can be close to the audience, to achieve the greatest visual opportunities. At the same time, for drivers, advertising particularly eye-catching.


3.Light and thin, easy to assemble and disassemble

The cabinet structure is thin and light not only reduces truck space occupied but also easy to dismount.



Truck led display not only used as mobile advertising media but also used as the display of temperature stage.


5.Super static electricity protection

To prevent running vehicle generated electrostatic damage the lights and driver IC of led display. To protect the safe operation of the display.


6.High Brightness, Better Quality

Installing at outdoor places require the displays to produce high brightness outputs. The high brightness and high definition features of the Truck LED Screen ensures great quality pictures - making it a perfect fit for promotion, station, stadium and other outdoor places.


Product parameter

Unit Module Item Parameter
Model Number P5-8S
Module size 320mm*160mm
Pixel pitch 5mm
Pixels Density 40000dots/m2
Pixel configuration 1R1G1B
LED Package mode SMD1921 or 2525
Pixel resolution 64dots(W)*32dots(H)
Max Power 45W
Module thickness 17.05mm
Weight 0.45kg
Drive type Constant drive
Scan mode 1/8scan
Port type HUB75
Brightness of white balance ≥5500cd/m2



Dimension 640mm*640mm
Monomer Module Number 8pcs
Power supply 5V/40A*2 pcs
Thermal discharge fan 1pcs
Pixel per cabinet 128mm*128mm
Best viewing distance 5M~100M
Best viewing angle 160°(W) 120°(H)



Relative humidity 10%-95%
Thickness 85mm
Power Working voltage AC220V±10%
Average Power consumption 390W/㎡
Max.Power consumption



Current ≤20mA(single LED)
Control system CPU Pentium4 or above P4
Operation system WIN98/2000/NT/XP/WIN7
Control method Synchronization

Main technical


Driving device Constant drive IC
Refresh frequency ≥1920HZ
Grey scale/colors 65536gray level/16.7M colors
MTBF ≥9000hours
Power switch Automatic switch
Display Mode ≥800*600/1024*768

Advertising 45W 6500cd/m2 P5 Truck Led Billboard 0

Advertising 45W 6500cd/m2 P5 Truck Led Billboard 1

Advertising 45W 6500cd/m2 P5 Truck Led Billboard 2

Packing & Delivery

Carton box:It is the cheapest packing method for the led display,which is mainly for the small screen and short shipping distance.
Wooden case:Wooden case is only for one time using transportation. After unpack, it cannot be used any longer. For the fixed installation ledpanel system, wooden case packing is the only way and the best way for packing since the low cost and same safety level for one timeusing..
Flight case: has wheels and handles which is for the rental use led display, to make the transportation be very convenient and protect the led display better..if your led display screen system is for the rental use, please choose the flight case for your led display screen.
Advertising 45W 6500cd/m2 P5 Truck Led Billboard 3

Our company

Shenzhen Mled melton optoelectronic technology co., LTD. specialized in manufacturing indoor and outdoor high-definition full-color LED display, LED lighting and lighting application products.Our company has professional production equipment and excellent technology, industry veteran, high-quality, high standards of modern management team, a high level of professional and technical developer, has many years of operating experience and well-trained, a significant number of skilled workers.
Our products has passed CE, FCC and ROHS certificate. reliable quality, advanced technology, perfect technology, automation of form a complete set of production equipment, standard production line, perfect sales network and good pre-sales after sales service is to provide high quality products and continuous development of our roots.
In recent years, our company has successively developed overseas agent channels such as the United States, Canada, the United Kingdom, Indonesia, Chile, Colombia, Turkey, etc., and its LED display products have also been exported to more than 100 countries and regions such as the United States, Russia, Sweden, Turkey, Poland, France, Israel, Argentina, Spain, etc


Our Service

1)Reply your inquiry in 24 working hours.

2)Experienced staffs answer all your query in fluent English,Spanish,French,German etc

3)Customized design is available,OEM & ODM are welcomed.

4)Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs.

5)Special discount and protection of sales area provided to our distributor

6)Warmly welcome your visit in our company if available.

7)Warranty: 24 months, a little investment for longer warranty time.
