Product Details:
Payment & Shipping Terms:
|
| Product Name: | High Quality Cheap Outdoor P4.81 Led Display Moudle For Advertising | Pixel Density: | 43222dot/㎡ |
|---|---|---|---|
| Pixel Configuration: | 1R1G1B | Pixel Resolution: | 52dots(W)*52dots(H) |
| Module Size: | 250mm*250mm | Scan Mode: | 1/13 Scan Static |
| Brightness Of White Balance: | ≥5500cd/㎡ | Dimension: | 500mm*1000mm |
| High Light: | led display board,smd led module |
||
Product description
1,easy to operate,easy installation and removal.
2,automatic fanless cooling desgin
3,flexible and easy to use
P4.81 outdoor module 250mm*250mm data sheet
| Item | P4.81 outdoor SMD 250mm*250mm | |
| 1 | Product Name | Oudoor P4.81 SMT High Definition Full Color 3 IN 1 |
| 2 | Pixel pitch | 4.81mm |
| 3 | Pixels density | 43222dot/㎡ |
| 4 | Pixel Configuration | 1R1G1B |
| 5 | Pixel resolution | 52dots(W)*52dots(H) |
| 6 | Module size | 250mm*250mm |
| 7 | LED Package mode | SMD2727 |
| 8 | Drive type | Constant drive |
| 9 | Scan mode | 1/13 scan static |
| 10 | Port type | HUB75 |
| 11 | Brightness of white balance | ≥5500cd/㎡ |
| 12 | Dimension | 500mm*1000mm |
| 13 | Pixel per cabinet | 104dot*208dot |
| 14 | Max.Power consumption(W/㎡) | ≤1200W/㎡ |
| 15 | Working voltage | 220VAC±15％ |
| 16 | Best viewing distance | ≥5M |
Packaging
(1) Carton box: It is the inexpensive packing method for the led display,which is mainly for the small screen and short shipping distance.
(2) Wooden case: Wooden case is only for one time using transportation.For the fixed installation ledpanel system, wooden case packing is the only way and the best way for packing
(3) Flight case: The LED air box is equipped with a clapboard and shock-proof cushioning material. It is shock-proof and shock-proof.Casters can be installed in the LED air box, which is highly mobile and flexible.Can be customized according to customer requirements；if your led display screen system is for the rental use, please choose the flight case for your led display screen.
Company information
1.Our company owns a group of high-quality professional and technical personnel and advanced modern sophisticated production equipment.
2.A reliable Chinese LED manufacturer, we strive to offer creative solutions, reliable products, and dependable service for our industry-leading LED display technologies.
Our factory
Our service
1. Can we make any size of led display?
Nope, according the led module size and cabient size, such as rental indoor led display, the smallest unit size is: 500x500mm.
2,How to install led display?
We will provide drawing of steel structure or Teamviewer to help you install.
3,How to order LED display?
Please tell me indoor or outdoor do you need,size of led display,where will the display be application of led display.
4,How to ship?
Normally, the display will be shipped by air and sea, because the value is high than other product too much.
