High quality cheap Outdoor P4.81 led display moudle for advertising

High quality cheap Outdoor P4.81 led display moudle for advertising
High quality cheap Outdoor P4.81 led display moudle for advertising

Large Image :  High quality cheap Outdoor P4.81 led display moudle for advertising

Product Details:
Place of Origin: China
Brand Name: MLED
Certification: CE-ROHS
Model Number: P4.81
Payment & Shipping Terms:
Minimum Order Quantity: 1piece
Price: USD 20-60 piece
Packaging Details: air flight case/cartoon case/poly wooden case
Delivery Time: 5-15work day
Payment Terms: L/C, D/A, T/T
Supply Ability: 100000 piece per month
Detailed Product Description
Product Name: High Quality Cheap Outdoor P4.81 Led Display Moudle For Advertising Pixel Density: 43222dot/㎡
Pixel Configuration: 1R1G1B Pixel Resolution: 52dots(W)*52dots(H)
Module Size: 250mm*250mm Scan Mode: 1/13 Scan Static
Brightness Of White Balance: ≥5500cd/㎡ Dimension: 500mm*1000mm
High Light:

led display board

,

smd led module

High quality cheap Outdoor P4.81 led display moudle for advertising

Product description



1,easy to operate,easy installation and removal.

2,automatic fanless cooling desgin

3,flexible and easy to use



P4.81 outdoor module 250mm*250mm data sheet



Item                          P4.81 outdoor SMD 250mm*250mm
1 Product Name Oudoor P4.81 SMT High Definition Full Color 3 IN 1
2 Pixel pitch 4.81mm
3 Pixels density 43222dot/㎡
4 Pixel Configuration 1R1G1B
5 Pixel resolution 52dots(W)*52dots(H)
6 Module size 250mm*250mm
7 LED Package mode SMD2727
8 Drive type Constant drive
9 Scan mode 1/13 scan static
10 Port type HUB75
11 Brightness of white balance ≥5500cd/㎡
12 Dimension 500mm*1000mm
13 Pixel per cabinet 104dot*208dot
14 Max.Power consumption(W/㎡) ≤1200W/㎡
15 Working voltage 220VAC±15%
16 Best viewing distance ≥5M



High quality cheap Outdoor P4.81 led display moudle for advertising 0High quality cheap Outdoor P4.81 led display moudle for advertising 1





High quality cheap Outdoor P4.81 led display moudle for advertising 2



Packaging

High quality cheap Outdoor P4.81 led display moudle for advertising 3



(1) Carton box: It is the inexpensive packing method for the led display,which is mainly for the small screen and short shipping distance.



(2) Wooden case: Wooden case is only for one time using transportation.For the fixed installation ledpanel system, wooden case packing is the only way and the best way for packing



(3) Flight case: The LED air box is equipped with a clapboard and shock-proof cushioning material. It is shock-proof and shock-proof.Casters can be installed in the LED air box, which is highly mobile and flexible.Can be customized according to customer requirements;if your led display screen system is for the rental use, please choose the flight case for your led display screen.





Company information



1.Our company owns a group of high-quality professional and technical personnel and advanced modern sophisticated production equipment. We implement strict quality management, making every LED module,LED display cabinet,Power supply ,Video processor ,LED display into competitive products, etc.

2.A reliable Chinese LED manufacturer, we strive to offer creative solutions, reliable products, and dependable service for our industry-leading LED display technologies.















Our factory



High quality cheap Outdoor P4.81 led display moudle for advertising 4





Our service



1. Can we make any size of led display?
Nope, according the led module size and cabient size, such as rental indoor led display, the smallest unit size is: 500x500mm.



2,How to install led display?
We will provide drawing of steel structure or Teamviewer to help you install.


3,How to order LED display?
Please tell me indoor or outdoor do you need,size of led display,where will the display be application of led display.



4,How to ship?
Normally, the display will be shipped by air and sea, because the value is high than other product too much.
