Uv Resistance Outdoor Full Color LED Display Billboard P10 IP65 For Building

Certification
China Melton optoelectronics co., LTD certification
China Melton optoelectronics co., LTD certification
Customer Reviews
lm very happy with packing and order. It was done and ready on time. Received order as expected. Will do business again with Penny and Anheer. They answered all my questions as fast as possible. P3 screen looks absolutely stunning. They did exactly as l asked the. I am very happy and they helped me set it up using TeamViewer. Thank you again Anheer

—— PETER B

La calidad es estable y el servicio es agradable. Somos una empresa de alquiler y venderemos más paneles a personas de Melton.

—— Carls

P10 في الهواء الطلق كامل اللون أدى العرض هو منتجنا الرئيسي في عام 2016 ، وأنه يجلب الكثير من الطلبات بالنسبة لي. نحن سعداء جدا وأيضا عملائنا.

—— Alfrode

Sempre relacionamento de longo prazo com a empresa MELTON OPTO, e de alta qualidade, bom serviço 24 horas, 7 dias, muito obrigado.Mr Liao

—— Ali

Felice di costruire una cooperazione a lungo termine con Melton, sono professionisti e responsabili, abbiamo fiducia in loro.

—— Refech

The double side led screen P16 effect is so perfect,i come to Melton factory and see them adjusting the led screen,they help me adjust and teach me.

—— Tal

Glad to cooperate with Melton Opto again,they are patient to answer each question.High quality,best service.

—— Ricardo

We are manufacturing bus displays with your LED modules, and so far there is no problems.

—— Sergo

We did a Rental P10 SMD 3528 led display for our National theatre project, The display is running well, no any blind lamp, the video is so clear.

—— Ari

옥외 광고 led 디스플레이 화면은 우리 나라에서 인기가 높습니다. P10, P8 DIP는 앞으로 큰 박수를 보게 될 것입니다. 신뢰 MELTON은 혜택을 공유 할 것입니다.

—— Lee Hans

Working with such a professional team is very comfortable.High quality and nice service are always equally done. I am happy to the LONG TERM relations

—— JUAN MERODA

Yüksek Kaliteli, Yaşam Süresi Hizmeti her zaman MELTON OPTO'yu takip eder, Herhangi bir sorun zamanında çözülür.

—— Axcun

I'm Online Chat Now

Uv Resistance Outdoor Full Color LED Display Billboard P10 IP65 For Building

Uv Resistance Outdoor Full Color LED Display Billboard P10 IP65 For Building
Uv Resistance Outdoor Full Color LED Display Billboard P10 IP65 For Building

Large Image :  Uv Resistance Outdoor Full Color LED Display Billboard P10 IP65 For Building

Product Details:
Place of Origin: China
Brand Name: MLED
Certification: CE/RoHS
Model Number: P10
Payment & Shipping Terms:
Minimum Order Quantity: 1 square meter
Price: USD390-400 Per Square Meter
Packaging Details: Carton box/ Poly wooden case/ Flight case
Delivery Time: 1-7 days
Payment Terms: L/C, D/A, T/T, Western Union, MoneyGram
Supply Ability: 100000 Pieces Per Month
Detailed Product Description
Produce Name: Factory Price High Temperature And Uv Resistance Outdoor P10 Large Screen Led Display Panel/ Led Billboard Brightness: 6800cd/m2
Waterproof: IP65 Led Lamp: Hongsheng Kinglight Nationstar
Driving Method: 1/4 Scan Constant Current Power Supply: Meanwell Delta G-enegry
Usage: Outdoor Building
High Light:

digital led display board

,

video display boards

High temperature uv resistance outdoor P10 large screen led display panel/ led billboard

Outdoor led display features

1. Outdoor LED display is of high brightness, with a general brightness of 5500cd and a maximum brightness of more than 10000cd. Even under the irradiation of strong light, it can be clearly seen with good display effect.



2. As a kind of advertising media, outdoor LED display screen has a variety of forms of advertising, which is more ornamental, wider and more attractive than traditional advertising.



Three, outdoor LED display advertising content update speed is fast, the administrator can change the display advertising content at any time according to the actual situation, the operation is relatively simple.



4. Outdoor LED display has good waterproof performance, strong uv resistance, protection grade above IP65, and can deal with all kinds of bad weather.



Product parameter



Unit Module
Item
Parameter
Model Number
P10-4S
Module size
320mm*160mm
Pixel pitch
10mm
Pixels Density
10000dots/m2
Pixel configuration
1R1G1B
Package mode
SMD3535
Pixel resolution
32dots(W)*16 dots(H)
Max Power
20W
Weight
0.45kg
Drive type
Constant drive
LED
Cabinet
Dimension
640mm*640mm
8Monomer Module Number
8
Power supply
5V/60A*1 pcs
Pixel per cabinet
64*64dots
Best viewing distance
6M~40M
Best viewing angle
160°(W) 120°(H)
Temperature
storage:-35℃~+85℃
working:-20℃~+50℃
Relative humidity
10%-95%
Thickness
80mm
Power
Working voltage
AC220V±10%
Average Power consumption
270W/㎡
Max.Power consumption
≤680W/㎡
Current
≤20mA(single LED)
Control system
CPU
Pentium4 or above P4
Operation system
WIN98/2000/NT/XP/WIN7
Control method
Synchronization
Main technical
parameter
Driving device
Constant drive IC
Refresh frequency
≥1200HZ
Grey scale/colors
4096 16.7M
4096gray level/16.7M colors
MTBF
≥9000hours
Power switch
Grade one
Display Mode
≥800*600/1024*768

Uv Resistance Outdoor Full Color LED Display Billboard P10 IP65 For Building 0

Uv Resistance Outdoor Full Color LED Display Billboard P10 IP65 For Building 1

Uv Resistance Outdoor Full Color LED Display Billboard P10 IP65 For Building 2

Packing & Delivery
Carton box:It is the cheapest packing method for the led display,which is mainly for the small screen and short shipping distance.
Wooden case:Wooden case is only for one time using transportation. After unpack, it cannot be used any longer. For the fixed installation ledpanel system, wooden case packing is the only way and the best way for packing since the low cost and same safety level for one timeusing..
Flight case: has wheels and handles which is for the rental use led display, to make the transportation be very convenient and protect the led display better..if your led display screen system is for the rental use, please choose the flight case for your led display screen.
Uv Resistance Outdoor Full Color LED Display Billboard P10 IP65 For Building 3

Our company
MELTON OPTOELECTRONICS co LTD is located in Jiada Industrial Area, Tangtou Rd,Shiyan Town,Bao'an DistitShenzhen city, Guangdong province,China., which covers an area of over 3500 square meters, Droductionworkshop 2500 square meters. With 10 high-speed SMT machine, and automatic production technoloay isadopted to ensure the quality of the product. Annual production of 86000 square meters. Annual sales of 200million yuan. Is a set research and development, production, sales, service as one of the LED display high-techenterprises. Company's main door inside and outside the full color LED display screen, supporting all kinds ofiron,aluminum, chemical fiber, such as housing. In the small distance between hd display and outdoor highlighted thedomestic
leading technology.

FAQ
Q1:What's the min order quantity?
A: LED screen 1 sqm / LED module 100pcs


Q2: What is the payment method?
A:We support a variety of payment methods. Normally by T/T,30% down payment,70% balance paid before shipping.


Q3: Is it ok to print my logo on led display product?
A: Yes, of course. If you need, pls inform us before our production.


Q4: How long is the delivery time?
A: It's about 15-25days after confirmation of the order.


Q5: How do you ship the goods and how long does take to arrive?
A: We usually ship by sea or air. By sea is about 30-40days; by air is about 3-7days.


Q6: What's the control system do you use?
A: Our standard control system is Linsn or Novastar. Also support other controlling system, like Huidu,Sheenled,Colorlight etc.


Q7: Do you have any certification for LED display?
A: Yes, we have CE,ROHS,FCC certification.


Q8: How about the guarantee of led display?
A: We guarantee all our displays, modules, spare parts for two years.
During this time, we will replace or remand our goods for free if there is something wrong with them.
