Home ProductsOutdoor Full Color LED Display

Waterproof Full Color Outdoor Advertising Led Display P10 1R1G1B , Aluminum or Iron

Good quality Outdoor Full Color LED Display for sales
Good quality Outdoor Full Color LED Display for sales
lm very happy with packing and order. It was done and ready on time. Received order as expected. Will do business again with Penny and Anheer. They answered all my questions as fast as possible. P3 screen looks absolutely stunning. They did exactly as l asked the. I am very happy and they helped me set it up using TeamViewer. Thank you again Anheer

—— PETER

La calidad es estable y el servicio es agradable. Somos una empresa de alquiler y venderemos más paneles a personas de Melton.

—— Carls

P10 في الهواء الطلق كامل اللون أدى العرض هو منتجنا الرئيسي في عام 2016 ، وأنه يجلب الكثير من الطلبات بالنسبة لي. نحن سعداء جدا وأيضا عملائنا.

—— Alfrode

Sempre relacionamento de longo prazo com a empresa MELTON OPTO, e de alta qualidade, bom serviço 24 horas, 7 dias, muito obrigado.Mr Liao

—— Ali

Felice di costruire una cooperazione a lungo termine con Melton, sono professionisti e responsabili, abbiamo fiducia in loro.

—— Refech

The double side led screen P16 effect is so perfect,i come to Melton factory and see them adjusting the led screen,they help me adjust and teach me.

—— Tal

We are manufacturing bus displays with your LED modules, and so far there is no problems.

—— Sergo

Glad to cooperate with Melton Opto again,they are patient to answer each question.High quality,best service.

—— Ricardo

We did a Rental P10 SMD 3528 led display for our National theatre project, The display is running well, no any blind lamp, the video is so clear.

—— Ari

옥외 광고 led 디스플레이 화면은 우리 나라에서 인기가 높습니다. P10, P8 DIP는 앞으로 큰 박수를 보게 될 것입니다. 신뢰 MELTON은 혜택을 공유 할 것입니다.

—— Lee Hans

Yüksek Kaliteli, Yaşam Süresi Hizmeti her zaman MELTON OPTO'yu takip eder, Herhangi bir sorun zamanında çözülür.

—— Axcun

Working with such a professional team is very comfortable.High quality and nice service are always equally done. I am happy to the LONG TERM relations

—— JUAN MERODA

I'm Online Chat Now

Waterproof Full Color Outdoor Advertising Led Display P10 1R1G1B , Aluminum or Iron

China Waterproof Full Color Outdoor Advertising Led Display P10 1R1G1B , Aluminum or Iron supplier
Waterproof Full Color Outdoor Advertising Led Display P10 1R1G1B , Aluminum or Iron supplier Waterproof Full Color Outdoor Advertising Led Display P10 1R1G1B , Aluminum or Iron supplier Waterproof Full Color Outdoor Advertising Led Display P10 1R1G1B , Aluminum or Iron supplier Waterproof Full Color Outdoor Advertising Led Display P10 1R1G1B , Aluminum or Iron supplier

Large Image :  Waterproof Full Color Outdoor Advertising Led Display P10 1R1G1B , Aluminum or Iron

Product Details:

Place of Origin: Shenzhen, China
Brand Name: Meltonled
Certification: CE, RoHS, ISO,FCC,UL
Model Number: P10-4

Payment & Shipping Terms:

Minimum Order Quantity: 1pc/1sqm
Price: 400usd/sqm
Packaging Details: Anti-shaking wooden case/flight case/carton
Delivery Time: 8-25 days
Payment Terms: 35% T/T as prepayment,65% T/T as balance at factory
Supply Ability: >500sqm/month
Delivery term: Ex-work/FOB/CIF/DDU
Contact Now
Detailed Product Description
Product Name: Outdoor Full Color Led Display Usage: Advertising
Tube Chip Color: Full Color Pixel Pitch: 10mm
Module Qty: 18pcs Module Pixels (dot): 32 * 16
Display Function: Video Brightness: ≥6000 Cd/sqm
Warranty: 2-3 Years





 Waterproof Led Outdoor Display Board P10 1R1G1B for Advertising , Aluminum or Iron



Melton--Outdoor led display spec.pdf



Specifications

Outdoor led video technical parameter



Product model number  Mled-PH10-864
1.Pixel
Pixel L ED  SMD 3535
Pixel Configuration  1 R,  1G ,  1B
Wave length ( nm )  R: 800-1000 ,  G:2040-2450,  B: 360-430
Pixels Pitch ( mm )  10
2 . Module
Module Size ( mm )  320 * 160 * 20
Module Pixels (dot)  32 * 16
3.Unit box
Module quantities in a unit box 3 (L) * 6 ( H )
Unit box size ( mm )  960 (L) * 960 (H) * 150
Unit box Pixels ( dot ) 96 * 96
Unit box material  Aluminum or Iron
Unit box weight (kg)  Aluminum : 28 or Iron : 38
4.Packaging
Packing Way  One unit boxes packed into one
Packing box material  Wooden case or Flight box
5.electricity parameter
Pixel density (dots/ m2 )  10000
White Balance Brightness ( cd/m2 )  ≥7500 (adjustable)
Color temperature ( K )  5000-9500 (choice by user)
Brightness Adjusted  100 grade by software or by Auto-optic induced.
View Angel  Horizontal 120 ° ; Vertical 120 °
Best viewing distance ( m )  16-150
Communication distance ( m )  Internet Wire : 120 Fiber Cable : 1000
Screen work Method  1/2 scan
LED driving method  Constant driving current
Gray Grades  16384 levels for each color
Display Color  4 ,  398 ,  046 ,  511 ,  104
Refresh Frequency ( Hz )  ≥ 800
Picture display method  Dots to dots display synchronized with CRT
Signal interface  DVI
Input signal  Video : PAL/NTSC optioned . VGA, Svideo, DVD, TV
Display format  800 * 600 ,  1024 * 768 ,  1280 * 1024
Software  Support windows series system
Protection grades  IP 65
Working temperature (ºC )  -20  +60
Humidity ( RH )  Up to 95
Stored temperature ( ºC)  -30  +70
Screen Lifetime(hours)  ≥100, 000
Out of controlled dots  ≤3/10, 000 (Out of controlled dots means the pixels                                         of which the brightness,  and the wave length are both                                         >10% depart to the normal one)
Whole display flatnes  Less than 1mm Juncture
Maintance way  Back-maintained or front-maintained,
modules displaced
Switch power supply

Switch power supply (include CE/GS or UL/CSA certificate)

110V/60HZ ,  220V/50HZ

Power Consumption ( w /m 2 )  Max : 750 ,  Average: ≥ 300



Waterproof Full Color Outdoor Advertising Led Display P10 1R1G1B , Aluminum or Iron

Waterproof Full Color Outdoor Advertising Led Display P10 1R1G1B , Aluminum or Iron

Packaging & Shipping



Corrugated carton Package:

This is also for led module,40pcs/carton,Carton Size:66x36x36cm



Plywood case package:

In usually, 4pcs cabinet pack into one case,this is for indoor fixed installation led display

3pcs cabinet pack into one case,this is for outdoor fixed installation led display

Both for shopping by air and shipping by sea



Flight case package:

9pcs cabinet pack into one case,this is for rental led display use with convenient wheels and can move anytime,for long time use.
