Product Details:
Payment & Shipping Terms:
|
| Product Name: | Discount Electronic P5/P6/P8/P10 Screen Prices Outdoor Advertising Full Color Led Display Price | Usage: | Advertising |
|---|---|---|---|
| Tube Chip Color: | Full Color | Pixel Pitch: | 10mm |
| Gray Scale: | 65536grade | Resolution(W*H): | 16dots*32dots |
| Waterproof: | IP65 | Cabinet: | Iron/aluminum |
| High Light: | digital led display board,video display boards |
||
Parameters for outdoor led screen
Usage
Service propaganda in finances, post offices, telecom, commerce, hospitals, sports stadiums
Policies and decrees issued from government organizations
Instructions, guidance and information issuance in airports and railways
Technical features of indoor advertising led billboard
1.Preeminent effects: Clear and stable pictures without distortion and disturbance.
2.High quality: adopting first-class chips and wafers imported from abroad
3.Flexible form: continuity, overlying, combination of dynamic and static playing,
various effects include rolling moving, typewriting, gradual changing and so on
4.off-line running function: adopting the monolithic design technology and computer
string communication way, which can operate in off-line state setting the dates and revising a data
via the telephone line
| Item | Parameter |
| Pixel Pitch | 10mm |
| Pixel Density | 10000 dots/sqm |
| LED Configuration | Red/Yellow |
| Module Size | 160mm * 160mm |
| Module Pixel | 16*32 dots |
| Ave. Consumption | 500 w/sqm |
| Max. Consumption | ≤1000 w/sqm |
| Brightness | More than 7500cd/sqm |
| Led sign Size | 960mm by 960mm / 1280mm by960mm |
| Grey scale | 14bit |
| View Distance | 10-100 m |
| View Angle | Horizontal: 120°, Vertical: 120° |
| Power Voltage | AC110V/220V/50 Hz |
| Drive Mode | 1/2Scan |
| Refresh Rate | >1000 Hz/s |
| Control Mode | WIFI,USB,Seria Port,Net port |
| Tolerance between modules | ≤1.5mm |
| Storage Temperature | Storage: - 35°C ~ + 85°C |
| Working Temperature | Working: '- 20°C ~ + 65°C |
| Input Source | DVI, S-Video, RGB, VGA etc |
| MTBF | ≥9,000 hours |
| Life span | ≥100,000 hours |
| Operation Humidity | 10% ~ 95% |
| Operation System | Windows 98, Windows2000, XP,Win7 |
Payment and Shipping
Many different payment terms are available for VISA,T/T,PAYPAL,E-CHECKING,WU,MONEYGRAM
By express door to door is DHL,UPS,TNT,FEDEX for urgent cargo and light weight<100kg
By air to airport for urgent cargo and weight <300kg
By sea to seaport is slow but cheap
