Outdoor Advertising P10 Full Color Led Display Screen High Brightness

Outdoor Advertising P10 Full Color Led Display Screen High Brightness
Outdoor Advertising P10 Full Color Led Display Screen High Brightness Outdoor Advertising P10 Full Color Led Display Screen High Brightness Outdoor Advertising P10 Full Color Led Display Screen High Brightness Outdoor Advertising P10 Full Color Led Display Screen High Brightness

Large Image :  Outdoor Advertising P10 Full Color Led Display Screen High Brightness

Product Details:
Place of Origin: Shenzhen, China
Brand Name: Meltonled
Certification: CE, RoHS, ISO,FCC,UL
Model Number: P10-M10-N24
Payment & Shipping Terms:
Minimum Order Quantity: 1pc/1sqm
Price: 590usd/sqm
Packaging Details: Anti-shaking wooden case/flight case/carton
Delivery Time: 7-15 working days
Payment Terms: 35% T/T as prepayment,65% T/T as balance at factory, MoneyGram, Western Union
Supply Ability: >500sqm/month
Detailed Product Description
Product Name: Nationstar KINGDIGITALS Outdoor Advertising Led Display Screen Billboard Prices Usage: Outdoor
Tube Chip Color: Full Color Pixel Pitch: 10mm
Pixel Composition: 1R1G1B LED Dots Per Square Meter: 10000
Waterproof: IP65 Brightness: 10000cd
High Light:

ledoutdoor billboards


digital led billboards


Outdoor Advertising P10 Full Color Led Display Screen High Brightness


Item Techinical Specifications
Pixel Pitch 8mm 10mm 12mm 16mm
LED Configuration SMD 3-in-1(SMD3535) DIP246 (1R1G1B) DIP246 (1R1G1B) DIP246 (1R1G1B)
Pixel Density 15625 pixels/sq.m 10000 pixels/sq.m 6944 pixels/sq.m 3906pixels/sq.m
Module Size 256mm*128mm 160mm*160mm 192mm*192mm 256mm*128mm
Module Resilution 32pixel*16pixel 16pixel*16pixel 16pixel*16pixel 16pixel*8pixel
Cabinet Size 1024mm*1024mm 960mm*960mm 960mm*960mm 1024mm*1024mm
Cabinet Resolution 128pixels*128pixels 96pixels*96pixels 80pixels*80pixels 64pixels*64pixels
Cabinet Material Iron/Aluminum Iron/Aluminum Iron/Aluminum Iron/Aluminum
Cabinet weight 50kg/sqm or 40kg/sqm 50kg/sqm or 40kg/sqm 50kg/sqm or 40kg/sqm 50kg/sqm or 40kg/sqm
Brightness 6000cd/sqm 8000cd/sqm 7500cd/sqm 8500cd/sqm
Colour temperature 3500K-9500K(adjustable) 3500K-9500K(adjustable) 3500K-9500K(adjustable) 3500K-9500K(adjustable)
Viewing Angle H:140°/V:140° H:110°/V:55° H:110°/V:55° H:110°/V:55°
Brightness Uniformity 97% 97% 97% 97%
Ave. Power consumption 240 W/sqm 200 W/sqm 200 W/sqm 240 W/sqm
Max. Power consumption 800W/sqm 600W/sqm 600W/sqm 800W/sqm
Best Viewing Distance 8 10 12 16
Contrast ratio 5000:1 5000:1 5000:1 5000:1
Frame rate 50/60 Hz/sec 50/60 Hz/sec 50/60 Hz/sec 50/60 Hz/sec
Refresh rate 1200Hz 1200Hz 1200Hz 1200Hz
Drive Mode 1/4 scan 1/4 scan 1/4 scan Static contant current
Brightness Adjustment Manual/Auto/Programmable
Input Voltage AC220V/50HZ or AC110V/60HZ (±10%)
Output Voltage 5V,40A
Grey scale levels R(256bit) x G(256bit) x B(256bit)
Display Colors R(1024) x G(1024) x B(1024)
Protection Level IP65
Life-span 100,000 hours
MTBF 10,000 hours
Malfunction dot rate < 0.0001
Storage Temp/Humidity -40~+65/10~90%RH
Operating Temp/Humidity -20~+65/10~90%RH
Control System Synchronous/Asynchronous/Wifi/3G Wireless for choice
PC Operating System Microsoft Windows 7, 8, 98, 2000, XP and Vista


Outdoor Advertising Led Display

1.Warranty:2 years
4.Waterproof IP65



high stability outdoor led billboard display


Features & Technical Specification:
1. Wide application field: Advertising LED display, Stadium perimeter LED display, Mobile LED display for mobile media, shopping mall LED display for logo showing, bank & stock exchange LED display for rates showing, train & bus station, airport, telecommunication LED screen system for information showing and instruction, Stage performances and so on.
2. High Contrast and Frequency: 4000: 1 and 5000Hz, which is a very high level to ensure a vivid image of our LED screen system.
3. First-class LED chip: Supplied by Silan & other high strictly selected LED chip to ensure the long life time and high brightness of our LED screen system.
4. Clear vivid image quality: Even in direct, full-on sunlight to ensure you attracts more audience to get short ROI of your LED screen's investment.
5. Long-term Brightness: 7500-nit brightness(for outdoor full color)(2000 nits brightness for indoor full color)capacity throughout product lifetime of the LED display.
6. Easy Installation & Using: Easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED screen system.
7. Convenient Servicing: Front or rear cabinet access make the maintains work very convenient and low cost to help you concentrate more time and energy on your main marketing promotion business.

Competitive Advantage:

1,  Good quality;

2,  Good price;

3,  Good 24hours service;

4,  Promote delivery;

5,  Energy-saving;

6,  Small order accepted.




Q1,How to arrange payment?

Our payment terms in usually is T/T payment,for sample and small order,Western union,Paypal or Moneygram also be acceptable


Q2,What is our warranty?

Our warranty from 5year to 1year basis on different type led screen,In usually every screen we will ready more extra led screen moduless as spare modules,if some modules happen fails,you can replace the fail modules by our spare modules,When all the spare modules use out,You can send back these modules to us for repair,and we will send to you after repair and testing&aging well


Q3,How to be our distributor?

To be our distributor,We can share our profit together with you in every year,Also we can send our engieer or sales to your compay to support your business,also for led screen after-service,We will together with you to the after-service in the whole led screen life time


Q4, How to maintence led screen?

In usually every year to maintence led screen one time,clear the led mask,checking the cables connection,if any led screen modules fail,you can replace it with our spare modules


Q5,How to select led type?

In usually,

For indoor stage will be select indoor die casting P2.5 P3 P4 P5 P6,P3.91 P4.81 P6.25

For outdoor stage will be select P4.81 P6.25 P6 P8 P10

For fixed installed led screen, can select P3 P4 P5 P6 P7.62 P10

For outdoor fixed installation,if it is not directly to sun,can select outdoor SMDP6 P8 P10,DIP P10 P12

if directly to sun,can select outdoor SMD P8, DIP P10

For big size led screen can select DIP P10 P12 P16 or P20

Also we have researched outdoor high resolution DIP 3in1: P4 P5 P6 P8 P10,there are good for high resolution led screen
