Product Details:
Payment & Shipping Terms:
|
| Certification: | CE,RoHs | Material: | Al |
|---|---|---|---|
| Cabinet: | Die Casting | Brightness: | >5000cd |
| CHIP: | Nationstar | Color: | Full Color |
| IP: | 65 | Warranty: | 2yrs |
| Application: | Stage | Weight: | 10kg/pc |
| Name: | 2016 Hot Sale Full Color Stage Rental LED Display Screen Of Magnet Front Service Cabinet | ||
| High Light: | led screen rental,led video rental |
||
Full Color Rental Led Stage Curtain Screen Display Magnet Front Service Cabinet
Specifications :
| Specification | PH8 | PH10 | H16 |
| Pixel Configuration | 1R1G1B | 1R1G1B | 1R1G1B |
| Density of pixel | 1/4 scan | 1/4 scan | Static |
| Module Resolution | 32*16(W*H) | 16*16(W*H) | 16*8(W*H) |
| Pixel density | 15625 | 10000 | 3906 |
| Pixel Pitch | 8mm | 10mm | 16mm |
| Best Viewing Distance | 6-12m | 7.5-15m | 12-24m |
| Module Size(mm) | 320*160 | 160*160 | 256*128 |
| Cabinet Size(mm) | 960*960 | 960*960 | 1024*768 |
| Weight | 55Kg | 55Kg | 47Kg |
| Working Voltage | AC220/110 ± 10%, 47~63Hz | ||
| Frame rate | 60Hz | ||
| Refresh rate | >1200Hz | ||
| Waterproof Rate | IP65 | ||
| Maxim Power | <450W | ||
| Average Power | <115W | ||
| Visual input | VGA mapped / NTSC/PAL | ||
| Input signal | S-video,VGA,PGB,Composite Video,SDI etc | ||
| Viewing Angle | Horizontal:≥ 120° Vertical:≥60° | ||
| Brightness | >8500 cd | ||
| Working Temperature | -20ºC to +60ºC | ||
| Control mode | Synchronized with PC | ||
| Continuous working time | >48 hours | ||
| Scotoma Rate | <0.0002 | ||
| Operating humidity | 20% to 90% | ||
| Lifespan (50% Brightness) | 100,000 hours |
||
Advantages:
1. Light weight: it can be loaded by one person, quick assembling, quick maintain, reduce. carrying, save costs.
2.Thin cabinet:the thickness isonly10 CM, the space of the screen is small , and the entire screen will be more beautiful.
3. Flat screen: smooth surface error is under 0.2cm, it can remove the mosaic phenomenon .effectively.
The effect of the display will be more clear and exquisite.
4. Quick dismounting: adopt fast locking structure connected, firm, quick, beautiful.
5. Low release heat: low noise, low consumption, low cost, excellent thermal design and excellent thermal dispersion.
6. Full compatible: new structure design which can demand the indoor displays’ require.
1)Outdoor led video System structure
Competitive Advantage:
1, Good quality;
2, Good price;
3, Good 24hours service;
4, Green product;
5, Fast delivery time.
| Training | Free of charges;In our workshop, we provide all the training including process of operation, installation, maintenance, system set up, etc. |
| Warranty |
1, 2years, .From beginning of installation finished the led display, During it , we will be responsible for all the quality problem. 2, After the completion of the project, we will conduct life maintenance of the system continuously and update the and software. 3, For the hardware equipment, we only collect expenses on components. |
| Guarantee |
1, All the life time for Technology support , system update ,maintenance . 2, We guarantee that the equipment we provide are brand new, complete and unused before delivery . |
|
Remark
|
1. We are manufacturer of LED display. We only provide the Screen, Cabinet and module, but do not take charge for the installation in overseas; Technical support is available. 2. The above offer included the cabinet, power supply, power cord,and other basic components; etc. 3. The above offer do NOT included the delivery, insurance, installation and debugging cost; 4. Packing with Ply-wood box, or Carton ; If need flight case packing, up cost will be USD180/PC, 2-4cabinets/case 5.Problems during use. some spare parts for you, once the screen get problems, please follow up below steps to solve it: Step1: Take some pictures about the working status of the screen; Step2: Replace the broken cabinet by the new cabinet; Step3: Contact with us, and send the pictures to us, we will help you to analyze the problems. Step4: If it is necessary, please post it to our company, we will maintain it for you as soon as possible, and then deliver it to you. |
