IP65 waterproof electronic advertising led display , led outdoor billboards

IP65 waterproof electronic advertising led display , led outdoor billboards
IP65 waterproof electronic advertising led display , led outdoor billboards

Large Image :  IP65 waterproof electronic advertising led display , led outdoor billboards

Product Details:
Place of Origin: Shenzhen, China
Brand Name: Meltonled
Certification: CE, RoHS, ISO,FCC,UL
Model Number: P6-M10-N26
Payment & Shipping Terms:
Minimum Order Quantity: 1pc/1sqm
Price: 390-420usd/sqm
Packaging Details: Anti-shaking wooden case/flight case/carton
Delivery Time: 12-15 working days
Payment Terms: 35% T/T as prepayment,65% T/T as balance at factory, MoneyGram, Western Union, L/C
Supply Ability: >5000sqm/month
Detailed Product Description
Product Name: Ip65 Waterproof Outdoor Electronic Advertising Led Display Screen Flexible Billboard Display Usage: Outdoor
Tube Chip Color: Full Color Pixel Pitch: 6mm
Pixel Composition: 1R1G1B LED Dots Per Square Meter: 27777
Waterproof: IP65 Brightness: 6000cd
High Light:

ledoutdoor billboards

,

outdoor advertising led display

,

IP65 waterproof led outdoor billboards

IP65 waterproof electronic advertising led display , led outdoor billboards

Specifications

P6 OUTDOOR SMD 3IN1 TECHNICAL PARAMETERS





Unit Module

Item Parameter
Model Number P6-8S
Module size 192mm*192mm
Pixel pitch 6mm
Pixels Density 27777dots /m2
Pixel configuration 1R1G1B
LED Package mode SMD3535/2727
Pixel resolution 32dots(W)*32dots(H)
Max Power 35W
Module thickness 17.05mm
Weight 0.369kg
Drive type Constant drive
Scan mode 1/8scan
Port type HUB75
Brightness of white balance >6000cd/m2

IP65 waterproof electronic advertising led display , led outdoor billboards 0

LED

Cabinet

Dimension 576mm*576mm
Monomer Module Number 9pcs
Power supply 5V/60A*1 pcs
Thermal discharge fan 1pcs
Pixel per cabinet 96mm*96mm
Best viewing distance 6M 40M
Best viewing angle 160 (W) 120 (H)
Temperature

storage:-35 +85

working:-20 +50

Relative humidity 10%-95%
Thickness 85mm



IP65 waterproof electronic advertising led display , led outdoor billboards 1



Power

Working voltage AC110V 220V 10%
Average Power consumption <380W/sqm
Max.Power consumption <950W/sqm
Current <20mA(single LED)



Control system

CPU Pentium4 or above P4
Operation system WIN98/2000/NT/XP/WIN7
Control method Synchronization



Main technical

parameter

Driving device Constant drive IC
Refresh frequency >1200HZ
Grey scale/colors

16384 , 16.7M

16384gray level/16.7M colors

MTBF >9000hours
Power switch Automatic switch
Display Mode 800*600/1024*768



IP65 waterproof electronic advertising led display , led outdoor billboards 2



FAQ:



Q1,How to arrange payment?

Our payment terms in usually is T/T payment,for sample and small order,Western union,Paypal or Moneygram also be acceptable



Q2,What is our warranty?

Our warranty from 5year to 1year basis on different type led screen,In usually every screen we will ready more extra led screen moduless as spare modules,if some modules happen fails,you can replace the fail modules by our spare modules,When all the spare modules use out,You can send back these modules to us for repair,and we will send to you after repair and testing&aging well



Q3,How to be our distributor?

To be our distributor,We can share our profit together with you in every year,Also we can send our engieer or sales to your compay to support your business,also for led screen after-service,We will together with you to the after-service in the whole led screen life time



Q4, How to maintence led screen?

In usually every year to maintence led screen one time,clear the led mask,checking the cables connection,if any led screen modules fail,you can replace it with our spare modules



Q5,How to select led type?

In usually,

For indoor stage will be select indoor die casting P2.5 P3 P4 P5 P6,P3.91 P4.81 P6.25

For outdoor stage will be select P4.81 P6.25 P6 P8 P10

For fixed installed led screen, can select P3 P4 P5 P6 P7.62 P10

For outdoor fixed installation,if it is not directly to sun,can select outdoor SMDP6 P8 P10,DIP P10 P12

if directly to sun,can select outdoor SMD P8, DIP P10

For big size led screen can select DIP P10 P12 P16 or P20

Also we have researched outdoor high resolution DIP 3in1: P4 P5 P6 P8 P10,there are good for high resolution led screen
