Product Details:
Payment & Shipping Terms:
|
| Product Name: | Led Billboard Display | Usage: | Outdoor |
|---|---|---|---|
| Tube Chip Color: | Full Color | Pixel Pitch: | 10mm |
| Pixel Composition: | SMD 3IN1 | Cabinet Size: | 960*960 Mm Or Customer's Required |
| Driving IC: | MBI5024 | Refresh Frequency: | More Than 800Hz/S |
| High Light: | digital led billboards,outdoor advertising led display,SMD 3in1 Led Billboard Display |
||
Specifications
P10 OUTDOOR SMD 3IN1 TECHNICAL PARAMETERS
|
Unit Module |
Item | Parameter |
| Model Number | P10-4S | |
| Module size | 320mm*160mm | |
| Pixel pitch | 10mm | |
| Pixels Density | 10000 /m2 | |
| Pixel configuration | 1R1G1B | |
| LED Package mode | SMD3535 | |
| Pixel resolution | 32dots(W)*16 dots(H) | |
| Max Power | 30W | |
| Module thickness | 17.05mm | |
| Weight | 0.37kg | |
| Drive type | Constant drive | |
| Scan mode | 1/4can | |
| Port type | HUB75 | |
| Brightness of white balance | 5800cd/m2 |
|
LED Cabinet |
Dimension | 960mm*960mm |
| Monomer Module Number | 8pcs | |
| Power supply | 5V/60A*1 pcs | |
| Thermal discharge | fan 0pcs | |
| Pixel per cabinet | 960mm*960mm | |
| Best viewing distance | 10M 50M | |
| Best viewing angle | 160 (W) 120 (H) | |
| Temperature |
storage:-35 +85 working:-20 +50 |
|
| Relative humidity | 10%-95% | |
| Thickness | 85mm |
FAQ
Why choose MELTON OPTO?
1),Vivid and exact picture, minimum noise, advanced test equipment, support any pc operation system and play a variety of information like video, word, flash, music, clock, graph etc.
2),High brightness and support brightness automatically adjustment.
3),Long lifespan, can reach more than 100,000 hours, while the power consumption is lower than one tenth of lamp or neon;
4),Easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED display system;
5),Rich outdoor full color LED display screen engineering experience both in domestic and international market.
6),Well before, in,after-service.all for our customer reassurance.
