Outdoor P4mm SMD full color led display modules for big screen

Outdoor P4mm SMD full color led display modules for big screen
Outdoor P4mm SMD full color led display modules for big screen

Large Image :  Outdoor P4mm SMD full color led display modules for big screen

Product Details:

Place of Origin: Shenzhen, China
Brand Name: Meltonled
Certification: CE, RoHS
Model Number: PH4

Payment & Shipping Terms:

Minimum Order Quantity: 1pc/1sqm
Price: 380-400usd/sqm
Packaging Details: Anti-shaking wooden case/flight case/carton
Delivery Time: 8-10 days
Payment Terms: 35% T/T as prepayment,65% T/T as balance at factory, MoneyGram, Western Union
Supply Ability: >50000sqm/month
Delivery term: Ex-work/FOB/CIF/DDU
Detailed Product Description
Name: Outdoor P4mm SMD Full Color Led Display Modules For Big Screen Pixel: 4mm
Weight: 0.5kg/pc Brightness: 6000cd

Outdoor P4mm SMD full color led display modules for big screen



Description



1.Super Light and Thin



10KG/panel with a depth of 70mm which is half of the depth of traditional LED screen,saving space and transportation cost.



2.High Refresh Rate


Refresh Rate≥1920, offering impressive visual effect.



3.Noiseless


Free of fans and air conditions, excluding noise and reducing power consumption.



4.Fine and Smooth Picture


Drive IC of high refresh rate and high grey scale to ensure stable picture and better visual effect of the screen.The latest horizontal-blanking circuit applied to completely eliminate phenomenon of blanking and smear.



5.Seamless Splicing


High conformity of picture without gap and information missing, realizing a seamless splicing display.



6.Fast Installation and Dismantlement.

Specification



Pixel Pitch 4mm
Pixel Density 62500dots/sqm
Color Configuration 1R1G1B
LED Package SMD1921
Module Size 256mm x 128mm
Module Resolution 128dots x 64dots
Drive Mode 1/8Scan
Cabinet Material Die casting Aluminum
Led Color White
Standard Cabinet Size 512mm x 512mm
Cabinet Weight 10KG
Brightness ≥5500 cd/sqm, adjustable by software
Viewing Distance 4m-40m
Viewing Angle H: 140°; V:140°
Refresh Rate 3840HZ, adjustable by software
Frame Rate 120frame/s
Grey Scale 16.7M colors(Synchronized)
Color Temperature R.G.B brightness 256 level adjustable
Power Input AC110V/ 220V ±10, 50HZ
Max Power Consumption 800W/sqm
Ave. Power Consumption 400W/sqm
Storage Temperature -30~+70 degree
Working Temperature -20~+50 degree
Blind Spot Rate <1/10000
MTBF >10,000 Hours
Life Span >100,000 Hours
Waterproof Level IP65
Operating Humidity 10%~90% RH
Control Method LINSN, NOVA, Colorlight
PC Display Resolution 1280x1024
Control PC With DVI Graphic card
Operating System Win 98, Win2000, XP, Win7, Win8,Win10
Video Signal Mode RF, S-Video, RGB, RGBHV, YUV, YC etc
Certificate CE, RoHS



FAQ:



Q: What about the quality?

A: We control the quality form the raw material, we only choose the qualified supplier to cooperate, and we have strictly inspection process, we know how to keep the brand value for both of us!
Q: Do you offer FREE sample?
A: We need to charge for the cost of the sample, however it can be refund if your place a lagre order.
Q: How many years of warranty can you offer?
A: We offer 1 year of warranty.If you need longer warranty, the price should be a little higher.
Q: What's the lead time for average order? What's the shipping time?
A: If module stock is available, the lead time is within 7 working days and for screen order, the lead time will be 15-25 working days.
