Wall Mounted IP65 Led Advertising Billboard , 1/4 scan Full Color Led Signs Outdoor

Wall Mounted IP65 Led Advertising Billboard , 1/4 scan Full Color Led Signs Outdoor
Wall Mounted IP65 Led Advertising Billboard , 1/4 scan Full Color Led Signs Outdoor Wall Mounted IP65 Led Advertising Billboard , 1/4 scan Full Color Led Signs Outdoor Wall Mounted IP65 Led Advertising Billboard , 1/4 scan Full Color Led Signs Outdoor Wall Mounted IP65 Led Advertising Billboard , 1/4 scan Full Color Led Signs Outdoor

Large Image :  Wall Mounted IP65 Led Advertising Billboard , 1/4 scan Full Color Led Signs Outdoor

Product Details:
Place of Origin: Shenzhen, China
Brand Name: Meltonled
Certification: CE, RoHS, ISO,FCC,UL
Model Number: P10-a-18
Payment & Shipping Terms:
Minimum Order Quantity: 1pc/1sqm
Price: 1-100000usd
Packaging Details: Anti-shaking wooden case/flight case/carton
Delivery Time: 8-25 days
Payment Terms: 35% T/T as prepayment,65% T/T as balance at factory
Supply Ability: >500sqm/month
Delivery term: Ex-work/FOB/CIF/DDU
Detailed Product Description
Product Name: Led Advertising Billboard Application: Outdoor
Tube Chip Color: Full Color Pixel Pitch: 10mm
Resolution(W*H): 16dots*16dots Module Size ( Mm ): 160 * 160 * 20
High Light:

led video billboard

,

digital advertising billboards

,

IP65 Led Advertising Billboard





Wall Mounted IP65  Led Advertising Billboard , 1/4 scan Full Color Led Signs Outdoor



Led Billboard Advertising Video Display Screen


Specifications



1.led outdoor waterproof video
2.Wide viewing angle video led
3.High brightness
4.Energy saving
5.CE.RoHS





OUTDOOR waterproof led video  from china factory



1.Show all kinds of word,text,graph, pictures, flashes, video,2-dimension, 3-dimension cartoon and any other

formats with your PC does synchronously.



2. Different signal resources input are acceptable, such as TV, HCTV, S-video, NTSC/PAL,DVI, AVI, VGA,SDI,

MOV,MPG,HD-SDI, etc.



3.Self-adjustment function

automatically adjusts outdoor LED display brightness to suitable level through outdoor environment condition



4.It can be used in advertisement, stage, stadium, exhibition, TV-Show,mansion video wall, shopping mall,

banks, schools, bus station, airport, gym, market, factories, monitoring centers,hospitals, bars etc.

1)Outdoor led video System structure  Wall Mounted IP65 Led Advertising Billboard , 1/4 scan Full Color Led Signs Outdoor 0



2)outdoor led video Module

Wall Mounted IP65 Led Advertising Billboard , 1/4 scan Full Color Led Signs Outdoor 1



Module Size(W * H)

160mm*160mm

Pixel Configeration

1R,1G,1B

Pixel Pitch

10mm

Resolution(W*H)

16dots*16dots

Pixel Density

10000 dot / m2

Driving Method

1/4 scan Current



3)led video cabinet

Wall Mounted IP65 Led Advertising Billboard , 1/4 scan Full Color Led Signs Outdoor 2

Cabinet Size(W * H)

960mm*960mm

Module Qty

36pcs

Cabinet Resolution(W * H)

96dots*96dots

Cabinet Pixel

9216

Weight

50kg/pc

Area

0.9216(m2)

Avarage Power Consumption

200W/m2

Max Consumption

600W



4)Program diagram

Wall Mounted IP65 Led Advertising Billboard , 1/4 scan Full Color Led Signs Outdoor 3

5)Outdoor led video technical parameter

Product model number  Mled-PH10-864
1.Pixel
Pixel L ED  348
Pixel Configuration  1 R,  1G ,  1B
Wave length ( nm )  R: 800-1000 ,  G:2040-2450,  B: 360-430
Pixels Pitch ( mm )  10
2 . Module
Module Size ( mm )  160 * 160 * 20
Module Pixels (dot)  16 * 16
3.Unit box
Module quantities in a unit box 6 (L) * 6 ( H )
Unit box size ( mm )  960 (L) * 960 (H) * 150
Unit box Pixels ( dot ) 96 * 96
Unit box material  Aluminum or Iron
Unit box weight (kg)  Aluminum : 40 or Iron : 55
4.Packaging
Packing Way  Two unit boxes packed into one
Packing box material  Wooden case or Flight box
5.electricity parameter
Pixel density (dots/ m2 )  10000
White Balance Brightness ( cd/m2 )  ≥7500 (adjustable)
Color temperature ( K )  5000-9500 (choice by user)
Brightness Adjusted  100 grade by software or by Auto-optic induced.
View Angel  Horizontal 120 ° ; Vertical 70 °
Best viewing distance ( m )  16-150
Communication distance ( m )  Internet Wire : 120 Fiber Cable : 1000
Screen work Method  1/4 scan
LED driving method  Constant driving current
Gray Grades  16384 levels for each color
Display Color  4 ,  398 ,  046 ,  511 ,  104
Refresh Frequency ( Hz )  ≥ 800
Picture display method  Dots to dots display synchronized with CRT
Signal interface  DVI
Input signal  Video : PAL/NTSC optioned . VGA, Svideo, DVD, TV
Display format  800 * 600 ,  1024 * 768 ,  1280 * 1024
Software  Support windows series system
Protection grades  IP 65
Working temperature (ºC )  -10  +50
Humidity ( RH )  Up to 95
Stored temperature ( ºC)  -30  +70
Screen Lifetime(hours)  ≥100, 000
Out of controlled dots  ≤3/10, 000 (Out of controlled dots means the pixels                                         of which the brightness,  and the wave length are both                                         >10% depart to the normal one)
Whole display flatnes  Less than 1mm Juncture
Maintance way  Back-maintained or front-maintained,
modules displaced
Switch power supply

Switch power supply (include CE/GS or UL/CSA certificate)

110V/60HZ ,  220V/50HZ

Power Consumption ( w /m 2 )  Max : 750 ,  Average: ≥ 300







Competitive Advantage:



1,  Good quality;

2,  Good price;

3,  Good 24hours service.
