High brightness IP65 Waterproof P5 Full Color Led Billboard/ Advertising Kiosk

Certification
China Melton optoelectronics co., LTD certification
China Melton optoelectronics co., LTD certification
Customer Reviews
lm very happy with packing and order. It was done and ready on time. Received order as expected. Will do business again with Penny and Anheer. They answered all my questions as fast as possible. P3 screen looks absolutely stunning. They did exactly as l asked the. I am very happy and they helped me set it up using TeamViewer. Thank you again Anheer

—— PETER B

La calidad es estable y el servicio es agradable. Somos una empresa de alquiler y venderemos más paneles a personas de Melton.

—— Carls

P10 في الهواء الطلق كامل اللون أدى العرض هو منتجنا الرئيسي في عام 2016 ، وأنه يجلب الكثير من الطلبات بالنسبة لي. نحن سعداء جدا وأيضا عملائنا.

—— Alfrode

Sempre relacionamento de longo prazo com a empresa MELTON OPTO, e de alta qualidade, bom serviço 24 horas, 7 dias, muito obrigado.Mr Liao

—— Ali

Felice di costruire una cooperazione a lungo termine con Melton, sono professionisti e responsabili, abbiamo fiducia in loro.

—— Refech

The double side led screen P16 effect is so perfect,i come to Melton factory and see them adjusting the led screen,they help me adjust and teach me.

—— Tal

Glad to cooperate with Melton Opto again,they are patient to answer each question.High quality,best service.

—— Ricardo

We are manufacturing bus displays with your LED modules, and so far there is no problems.

—— Sergo

We did a Rental P10 SMD 3528 led display for our National theatre project, The display is running well, no any blind lamp, the video is so clear.

—— Ari

옥외 광고 led 디스플레이 화면은 우리 나라에서 인기가 높습니다. P10, P8 DIP는 앞으로 큰 박수를 보게 될 것입니다. 신뢰 MELTON은 혜택을 공유 할 것입니다.

—— Lee Hans

Working with such a professional team is very comfortable.High quality and nice service are always equally done. I am happy to the LONG TERM relations

—— JUAN MERODA

Yüksek Kaliteli, Yaşam Süresi Hizmeti her zaman MELTON OPTO'yu takip eder, Herhangi bir sorun zamanında çözülür.

—— Axcun

I'm Online Chat Now

High brightness IP65 Waterproof P5 Full Color Led Billboard/ Advertising Kiosk

High brightness IP65 Waterproof P5 Full Color Led Billboard/ Advertising Kiosk
High brightness IP65 Waterproof P5 Full Color Led Billboard/ Advertising Kiosk

Large Image :  High brightness IP65 Waterproof P5 Full Color Led Billboard/ Advertising Kiosk

Product Details:
Place of Origin: China
Brand Name: MLED
Certification: CE/ROHS
Model Number: P5
Payment & Shipping Terms:
Minimum Order Quantity: 10 Square Meters
Price: USD 613-616 Per square Meter
Packaging Details: Carton box/ Poly wooden case/ Flight case
Delivery Time: 15-18 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000 Square Meter Per Month
Detailed Product Description
Product Name: High Brightness IP65 Waterproof P5 Full Color Led Billboard/ Advertising Kiosk LED Chip: Nationstar/Sanan
Controller System: Novastar/LINSN LED Quality: Copper Leg
Brightness: >5800cd/m2 LED Cabinet: Diecasting Aluminum
Module Weight: 0.5kg Driving Method: 1/8 Scaning
High Light:

led video billboard

,

outdoor advertising led display

,

P5 Full Color Advertising Kiosk

High brightness IP65 Waterproof P5 Full Color Led Billboard/ Advertising Kiosk

Product features

1. Time efficiency

The purpose of the landing led advertising machine is to occupy the share of the advertising market. As the landing led advertising kiosk can carry out advertising communication beyond the constraints of time and space, so that the advertising can be carried out without the constraints of time and space, the media company will broadcast advertising at more times, and the landing led advertising kiosk is ready 24 hours a day. According to the requirements of many media companies, the general landing led advertising kiosk has a switch to broadcast advertising, useful to convey the effectiveness of advertising display.



2. Multimedia

The layout of landing led advertising kiosk can convey a variety of media information. Such as text, sound, image and other information, so that the ignorance of boring advertising into a more vivid, human. And can give full play to the creativity and initiative of the media company.



3. The personalized

The sales promotion on the landing led advertising kiosk is one-to-one, rational, customer-led, non-compulsive and progressive, and it is a low-cost and humanized promotion, to prevent the interference of the salesman's strong sales, and to establish long-term and outstanding relationship with customers through information supply.



4. The growth

The landing led advertising kiosk has become a group of young, middle class and highly educated advertising viewers. As this group has strong purchasing power and strong market influence, it is a potential way to develop the market.


Product parameter
Unit Module
Item
Parameter
Model Number
P5-8S
Module size
160mm*160mm
Pixel pitch
5mm
Pixels Density
40000dots/m2
Pixel configuration
1R1G1B
Package mode
SMD1921 or 2525
Pixel resolution
64dots(W)*32dots(H)
Max Power
45W
Weight
0.45kg
Drive type
Constant drive
LED
Cabinet
Dimension
640mm*640mm
8Monomer Module Number
8
Power supply
5V/40A*2 pcs
Pixel per cabinet
128mm*128mm
Best viewing distance
5M~100M
Best viewing angle
160°(W) 120°(H)
Temperature
storage:-35℃~+85℃
working:-20℃~+50℃
Relative humidity
10%-95%
Thickness
85mm
Power
Working voltage
AC220V±10%
Average Power consumption
390W/㎡
Max.Power consumption
≤980W/㎡
Current
≤20mA(single LED)
Control system
CPU
Pentium4 or above P4
Operation system
WIN98/2000/NT/XP/WIN7
Control method
Synchronization
Main technical
parameter
Driving device
Constant drive IC
Refresh frequency
≥1920HZ
Grey scale/colors
65536gray level/16.7M colors
MTBF
≥9000hours
Power switch
Grade one
Display Mode
≥800*600/1024*768



High brightness IP65 Waterproof P5 Full Color Led Billboard/ Advertising Kiosk 0
Product release way:

1.Remote real-rime control
2.Remote information release
3.Ads repeat play

How it work:
1.plug in the USB and it can play repeatly

High brightness IP65 Waterproof P5 Full Color Led Billboard/ Advertising Kiosk 1

Packing & Delivery



Our goods are packed with wooden case, flight case or according customer's request. Usually fixed installation led display use wooden case and die casting rental led display use flight case.

Carton box:It is the cheapest packing method for the led display,which is mainly for the small screen and short shipping distance.

Wooden case:Wooden case is only for one time using transportation. After unpack, it cannot be used any longer. For the fixed installation ledpanel system, wooden case packing is the only way and the best way for packing since the low cost and same safety level for one timeusing..

Flight case: has wheels and handles which is for the rental use led display, to make the transportation be very convenient and protect the led display better..if your led display screen system is for the rental use, please choose the flight case for your led display screen. Delivery Within 15-25 days after receiving deposit. If your order is very urgent, you should make it clear for us to prepare..



High brightness IP65 Waterproof P5 Full Color Led Billboard/ Advertising Kiosk 2

FAQ

Q1: What is the payment method?
A:We support a variety of payment methods. Normally by T/T,30% down payment,70% balance paid before shipping.



Q2: Is it ok to print my logo on led display product?
A: Yes, of course. If you need, pls inform us before our production.



Q3: How long is the delivery time?
A: It's about 15-25days after confirmation of the order.



Q4: How do you ship the goods and how long does take to arrive?
A: We usually ship by sea or air. By sea is about 30-40days; by air is about 3-7days.



Q5: What's the control system do you use?
A: Our standard control system is Linsn or Novastar. Also support other controlling system, like Huidu,Sheenled,Colorlight etc.



Q6: Do you have any certification for LED display?
A: Yes, we have CE,ROHS,FCC certification.



Q7: How about the guarantee of led display?
A: We guarantee all our displays, modules, spare parts for two years.
During this time, we will replace or remand our goods for free if there is something wrong with them
