Product Details:
Payment & Shipping Terms:
|
| Keywords: | Full Color HD LED Billboard Display , P8 P6 P5 LED Video Panel Wall 6500cd | Usage: | Indoor And Outdoor Advertising |
|---|---|---|---|
| Brightness: | 6500cd | Warranty: | 2 Years |
| Module Size: | 256*128mm | Life Span: | 100000hours |
| Application: | Indoor And Outdoor Advertising | Cabinet Size: | 768mm*768mm |
| Pixel Pitch: | 8mm | Refresh Rate: | 1200Hz |
| High Light: | digital led billboards,outdoor advertising led display,6500cd LED Billboard Display |
||
| Items | Vaules | |
|
Physical Parameter |
LED Configuration | 3in1(2121) |
| Pixel Pitch( mm) | 8mm | |
| Module Resolution (dots) | 32x16 | |
| Pixel Density (dots /m²) | 15625 | |
| Module Size(L x W )/( mm) | 256mm*128mm | |
| Cabinet Size(L x W )/( mm) | 768mm*768mm | |
| Cabinet Material | Die casting aluminum | |
| Module Weight( Per Module/kg) | 0.5kg | |
|
Optical Parameters |
Colors (Bit) | 14 |
| Grey Scale | 16384 | |
| Refresh Rate( Hz) | ≥1200 | |
| Scanning Mode | 1/16 | |
| White balance brightness | 6500cd | |
| Viewing Angle( H/V°) | 120/120 | |
|
Electrical Parameters |
Input Power( V) | AC110V/AC220V±10% |
| Max.Power Consumption( W/m²) | 850W | |
|
Operation Conditions |
Storage Temperature( ℃) | 15 - 50 |
| Working Temperature ( ℃) | -30 - 45 | |
| Storage Humidity ( RH) | 10%~90% | |
| Working Humidity( RH) | 10%~90% | |
| Lifespan( hrs) | ≥100000 | |
| Installation Way | Curved / Hanging / Fixed | |
| Maintenance Way | Front & Rear | |
1. Excellent visual effect, better viewing effect for text and graphic or video.
2. Large viewing angle,both H/V can reach 110 degree;getting vivid effect within any position of the viewing range;
3. High contrast ratio and good evenness, high uniformity,without mosaic.
4. Resist of the high temperature and antioxidation and anti-statiic;
5. Any led in each pixel can be respectively replaced, which reduce the cost of the display maintaince.
