Factory Low Price Customized size P8 Full Color Outdoor LED Display

Factory  Low Price Customized size P8 Full Color Outdoor LED Display
Factory  Low Price Customized size P8 Full Color Outdoor LED Display Factory  Low Price Customized size P8 Full Color Outdoor LED Display Factory  Low Price Customized size P8 Full Color Outdoor LED Display Factory  Low Price Customized size P8 Full Color Outdoor LED Display

Large Image :  Factory Low Price Customized size P8 Full Color Outdoor LED Display

Product Details:

Place of Origin: Shenzhen china
Brand Name: MLED
Certification: CE, RoHS, FCC, ISO9001, TUV
Model Number: P8

Payment & Shipping Terms:

Minimum Order Quantity: 1PC /1SQM
Price: USD520/sqm
Packaging Details: wooden box cartons flight care
Delivery Time: 5-25 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: <3500SQM per month
Detailed Product Description
Product Name: Factory Low Price Customized Size P8 Full Color Outdoor LED Display Tube Chip Color: Full Color
Usage: Outdoor,Advertising Board Pixels: 8mm
Screen Dimension: Customized Size,256*128mm Display Function: Video
Warranty: 2-3 Years Module Size: Customized,256*128mm
Power Supply: 110V~220V AC,Cl-power,G-energy,Meanwell / G-energy,meanwell Name: P8 Outdoor Led Screen
Application: Outdoor Advertising Led,Video Advertisement,Store
High Light:

video display boards

,

high resolution led display



Customized size P8 Full Color Outdoor Front Service LED Display





P8 Full Color Indoor Outdoor Front Service LED Display Screen for advertising is very hot sale for outdoor mediasolution series, it is very cost effective, and high refresh rate , also light weight design cabinet for options,
image quality is top, running stable, resolution is high density, plus simple installation to make this series more and more popular in indoor outdoor media screens.



TECHNICAL PARAMETER



Unit Module Item Parameter
Model Number P8-4S
Module size 256mm*128mm
Pixel pitch 8mm
Pixels Density 15625dots/m2
Pixel configuration 1R1G1B
Package mode SMD3535
Pixel resolution 32dots(W)*16 dots(H)
Max Power 35W
Module thickness 17.05mm
Weight 0.343kg
Drive type Constant drive
Scan mode 1/4scan
Port type HUB75-A
Brightness of white balance ≥6500cd/m2





LED

Cabinet

Dimension 768X768mm
Monomer Module Number 18piece
Power supply 5V/60A*3 pcs or 5V40A 4pcs
Thermal discharge
Pixel per cabinet 128X128dots
Best viewing distance 8M~40M
Best viewing angle 160°(W) 120°(H)
Temperature

storage:-35℃~+85℃

working:-20℃~+50℃

Relative humidity 10%-95%
Thickness 135mm





Power Working voltage AC220V±10%
Average Power consumption 280W/㎡
Max.Power consumption

≤700W/㎡



Current ≤20mA(single LED)
Control system CPU Pentium4 or above P4
Operation system WIN98/2000/NT/XP/WIN7
Control method Synchronization

Main technical

parameter

Driving device Constant drive IC
Refresh frequency ≥1200HZ
Grey scale/colors

4096 16.7M

4096gray level/16.7M colors

MTBF ≥9000hours
Power switch Automatic switch
Display Mode ≥800*600/1024*768



Factory  Low Price Customized size P8 Full Color Outdoor LED Display 0





Factory  Low Price Customized size P8 Full Color Outdoor LED Display 1Factory  Low Price Customized size P8 Full Color Outdoor LED Display 2
